YMSJ Super Fine Corn Grits Machine

Machine

YMSJ Super Fine Corn Grits Machine

YMSJ super fine corn grits machine is the core equipment for producing corn grits.

YMSJ super fine corn grits machine introduction:
It is the core equipment for producing corn grits.
It has high grits yield.

Working principle:
It consists of rotor, upper and lower casing, pelletizing chamber, kneading toothed plate, sieve plate, motor and rack. When the raw material enters into the pelletizing chamber, under the strike and shearing effect of the professional shear type blade, the cut material kneads and strikes with the sieve plate by the centrifugal drive, which makes the granules surface smooth and makes them become arc shape. The material granules which are smaller than the sieve pore are discharged out of the machine, and granules which are bigger than the sieve pore continue to be cut and stroke until they can pass the sieve pore.

Technical parameter:

Model
Power
(kw)
Yield
(kg/h)
Weight
(kg)
Rated Voltage
(V)
Size
(mm)
YMSJ32x16
7.5
1200
200
380
1100x1100x1400
YMSJ40x18
11
1500
320
380
1200x1200x1500
YMSJ56x40
22
2000
500
380
1300x1300x1600
YMSJ60x60
45
5000
750
380
1450×1400×1700

End products:
Uniform granularity, bright color and smooth surface.
Strong market competitiveness.


super fine corn grits making machine.jpg
