    • YTZF-28-40 Corn Meal (Posho) Machine
      Writer: Corn Meal Machine From: Corn Meal (Posho) Machine
      Size: Big Medium Small Time: 2017-09-18 14:29:40

       YTZF-28-40 Corn Meal (Posho) Machine Introduction:



      YTZF-28-40 Corn Meal Machine is our newly developed corn processing equipment based on African market demand and the local diet tradition, especially the demand in white corn flour milling.



      YTZF-28-40 Corn Meal Machine consists of different functions together: corn peeling, polishing, degerming, cleaning and flour milling and can produce corn flour directly used in cooking. It is the ideal equipment for large quantity of corn processing enterprises and individual users for its multi-functions, compact structure, high efficiency and low energy consumption.



      YTZF-28-40 Corn Meal Machine Structure and Working Principle:

      1.It is mainly composed of the following parts: conveying, peeling, air blowing, flour milling, dedusting, transmission and machine frame.

      2.After cleaning, corn is blended with a small quantity of water(≤3%), and then is conveyed to the moistening barn for 7-10 minutes. Then it is sent into the peeling chamber for peeling. The mutual friction among corn, high-speed rotation iron roller and sieve plate damages the bonding strength among the corn endosperm, corn bran and corn germ and makes them separated.

      After peeling, corn kernels are sent into the grinding chamber and are milled under the force of high-speed rotation, impacting and shearing. The granules smaller than the sieve plate mesh are discharged out of the machine. And the larger ones are processed repeatedly.

      Then the mixing material is sent into the filtration fabric for air exhausting. At last, the flour is collected and packaged.



      YTZF-28-40 Corn Meal Machine Technical Parameter:

      Model



      Raw Grain

      Yield
      (kg/h)
      Air Volume
      (m³/h)
      Weight
      (kg)
      Power
      (kW)
      Bran Rate
      (%)
      Powder Fineness
      (mesh)
      Boundary
      Dimension
      (mm)
      YTZF-28-40
      corn
      600-700
      2200-2600
      230
      7.5
      19-30
      30-60

       1600×1150×1800
      paddy
      350-450
      40-60
      bean
      250-350
      40-60
